Material Construction
The inner tank of IBT is made up of high-grade GI sheet & it has proper insulation of high-density Polyurethane foam (PUF).
Storage Capacity
Chilled water storage ranges between 2000 ltr to 20000 ltr. It can be customized as per plant and client requirement.
Cooling Capacity
Cooling range between 0°C to 4°C, ideal for milk and perishable products. Refrigeration load ranges between 5 KW and 500 KW. It depends on the uses and application size.
Compressor Type
Water cooled or air cooled compressors are used for efficient refrigeration. It is built to support single or multiple compressors based on capacity and requirement.
Refrigerant Options
It is compatible with eco-friendly refrigerants i.e. - R22 & R404.
Agitation System
The motor of agitator is of high-performance having speed controller with horse power range of 1 HP to 5 HP (depending on tank size). This ensures uniform temperature distribution.
Piping and Fittings
Material of stainless steel (SS304) or food-grade PVC for hygiene with diameter according to requirement to match the uses.
Electrical Specifications
Voltage of 220V or 440V (single-phase or three-phase options). Digital display control panel with PLC & HMI. It is easy to operate and monitor.
Insulation Thickness
Insulation thickness is between 50 mm to 150 mm of high-density Polyurethane foam (PUF) based on the operational conditions and environment.
Temperature Sensors
Accuracy of ±0.5°C with multiple sensors for sensitive temperature with easy control and monitoring.
Heat Exchanger Compatibility
It works seamlessly with plate heat exchangers (PHE) for dairy cooling.
Corrosion Resistance
All components are designed to resist corrosion for long-term use. It is supposed to be cleaned at regular intervals.
Drainage System
It is an efficient water/ice melt drainage system to prevent overflow or contamination.
Weight
The weight varies on the capacity and material used.
Compliances
It is totally approved with various certifications like ISO, CE, and BIS standards for quality assurance.
Optional Features
It is built to support battery backup or diesel generator. There are scalable options to add capacity as per future requirements.
